Product Introduction

5.IM3001 and IM3003 Vertical Flange-Mounted Motor Without Foot YZR112-315

5. IM3001 and IM3003 Vertical Flange-Mounted Motor Without Foot YZR112-315

Frame	Mounting Dimension & Tolerance																									Overall Dimension
	Flange symbol	M	N		P	LA	T	S		Screw		D		D1	E		E1	Key				key way				L	LB	AD
			Dimension	Tolerance				Dimension	Tolerance	Diamesion	Amount	Dimension	Tolerance		Dimension	Tolerance		F(h9)		GD		F(N9)		G
																		Dimension	Tolerance	Dimension	Tolerance	Dimension	Tolerance	Dimension	Tolerance
112M	F215	215	180	+0.014 -0.011	250	14	4	15	+0.43 0	M12	4	32	+0.018 +0.002	-	80	±0.37	-	10	0 -0.036	8	0 -0.09	10	0 -0.036	27	0 -0.2	595	515	220
132M	F265	265	230	+0.016 -0.013	300							38												33		645	565	230
160M	F300	300	250		350	18	5	19	+0.52 0	M16		48			110	±0.43		14	0 -0.043	9		14	0 -0.043	42.5		828	718	250
160L																										872	762
180L												55	-	M36×3			82							19.9		915	805	280
200L	F400	400	350	±0.018	450	20					8	60		M42×3	140	±0.50	105	16		10		16		21.4		1050	910	320
225M												65												23.9		1110	970
250M	F500	500	450	±0.020	550	22						70		M48×3				18		11	0 -0.11	18		25.4		1266	1126	355
280S												85		M56×4	170		130	20	0 -0.052	12		20	0 -0.052	31.7		1370	1200	385
280M																										1420	1250
315M	F600	600	550	±0.022	660	25	6	24		M20		95		M64×4				22		14		22		35.2		1525	1355	430
